1, Automatic feeding roll material, and taking out products.
2, Automatic vacuum forming.
3, Automatic printing, choose accessories.
4, Automatic roll of paper shelves, send out piece of material.
5, Automatic heat sealing area.
6, Automatic slitting, crosscutting.
7, Automatic cleaning and packing up waste.
Parameters：
|
Max packing width：
|
400mm
|
|
Mini packing width：
|
19mm
|
|
Max packing length：
|
398mm
|
|
Max vacuum depth：
|
60mm
|
|
Max printing length：
|
398mm
|
|
Max printing width：
|
396mm
|
|
Cycle time：
|
5-8s
|
|
Film width：
|
422-423mm
|
|
Paper width：
|
410mm
|
|
KWH：
|
380V×50HZ×9KW×3P+N+PE
|
|
Rated air pressure：
|
≥0.6Mpa
|
|
Cooling water：
|
＞5L/min，＜25℃
|
|
Weight：
|
about 2 t
|
|
Note：Printing is seperated.
|
|
